809-00 DASHBOARD, ASHTRAY & KNEE PADS, TRIM
Prev Diagram
Next Diagram
POS NO PART NO DESCRIPTION REMARK MODEL IN STOCK
1
91169-ashtraybracket 1969- Ashtray Mount UNAVAILABLE ALERT ME
1/2
911 552 055 70 Dashboard with centre nozzle leather, note additional shipping due to size/weight /LL 77- UNAVAILABLE ALERT ME
1/1
911 552 549 00 instrument cover bezel 76- UNAVAILABLE ALERT ME
2
911 552 409 00 cover for heating nozzle /L AVAILABLE
3
911 552 410 00 cover for heating nozzle /R AVAILABLE
5
999 591 310 40 Fixing clip, AVAILABLE
6
999 591 311 40 Dash pad attachment plastic snap-clip receptor (on chassis), . AVAILABLE
7
999 591 344 02 Latch, . AVAILABLE
8
N 011 524 7 Washer 6.4, superseded to n01152427 AVAILABLE
8
N01 152 427 Washer 6.4 UNAVAILABLE ALERT ME
9
999 090 003 02 Lock nut m6, . AVAILABLE
10
911 552 469 00 Trim, . AVAILABLE
(11)
911 552 041 10 Cover set, left, center, glovebox and right, black /LL 76 AVAILABLE
(11)
911 552 041 10 Cover set, left, center, glovebox and right, black /LL 77- AVAILABLE
15
911 552 071 00 side vent /L AVAILABLE
16
911 552 072 00 side vent /R AVAILABLE
17
911 552 463 00 trim radio UNAVAILABLE ALERT ME
18
911 552 217 00 rose lid-release cable fuel tank cap UNAVAILABLE ALERT ME
(19)
901 552 035 70 Knee protection strip, leather, /L UNAVAILABLE ALERT ME
(20)
901 552 036 70 Knee protection strip, leather, /R UNAVAILABLE ALERT ME
(21)
911 552 050 70 Ashtray handle, leather, UNAVAILABLE ALERT ME
22
901 552 061 25 Ashtray, superseded to 90155206125GRV AVAILABLE
23
901 552 607 00 fireproof plate AVAILABLE
24
900 076 027 02 Hexagon nut m5 superseded to 90007609101 AVAILABLE
25
900 151 027 02 Washer, superseded to 90015102703 UNAVAILABLE ALERT ME
25
900 151 027 03 Washer UNAVAILABLE ALERT ME
26
900 076 027 02 Hexagon nut m5 superseded to 90007609101 AVAILABLE
27
900 025 003 02 Washer, superseded to 90002508001 AVAILABLE
28
900 070 001 02 Cap nut m4, . AVAILABLE
29
900 028 018 01 Spring washer, superseded to n0122243 AVAILABLE
